Hunter I-20 Rotor with Check Valve and Pressure Regulator 4 in. | I20-04-PRB

In stock
SKU
I20-04-PRB
Free Shipping on Orders over $149
Sales Price $18.95 Our Price $35.06 You save 46%
Case of 20
$18.57 / each
Pallet of 1440
$18.19 / each

Hunter I20-04-PRB with Pressure Regulated Body

The PGP-04 and I-20 pressure regulated bodies will take incoming pressures of 50-100 PSI and reduce them to 45 PSI. The Hunter PRB rotors allow the nozzles to operate at peak efficiency, saving up to 25 percent more water. Having the pressure regulator in the body allows it to remain in place and functional even if the original riser is removed and replaced for service.

Features
  • Models: PGP Ultra: 4", I-20: 4", 6"
  • Arc setting: 50 to 360 degrees

  • Factory installed rubber cover
  • Through-the-top arc adjustment
  • QuickCheck arc mechanism
  • Water lubricated gear-drive
  • Includes: set of 12 nozzles (8 standard and 4 low angle), 1 adjustment tool per order, 1 set instructions
Operating Specifications
  • Radius: 17' to 46'
  • Flow rate: 0.36 to 9.8 GPM
  • Nozzle discharge pressure: 45 PSI
  • Operating pressure range: 55 to 100 PSI
  • Precipitation rates: 0.4 in/hr approx.
  • Nozzle trajectory: Std = 25 degrees, Low angle = 13 degrees
I-20-04-PRB Specs
  • Overall Height: 8-1/4"
  • Pop-up Height: 4"
  • Exposed Diameter: 1-3/4"
  • Inlet Size: 3/4"

Manuals and Literature

Documents
More Information
Brand Hunter
Type Rotor
Application Residential And Commercial
Inlet Size 3/4
Body Height 7-1/8
Pressure Range (PSI) 25-70
Warranty 5 Years
Pop-Up Height 4 in.
Check Valve Check Valve
Riser Material Plastic
Spray Pattern Part Circle Adjustable (50 - 360)
Advance Features Check Valve, Pressure Regulation, Flow Shut-Off
Specifications (499.79 kB)
Parts (234.96 kB)
