DIG 120 Mesh Disc Element Sets for 2 in. Long Filters | 17-046D

• Flow rates: 2 in.: up to 60 GPM (13.6 m3/h)
• Operating pressure: up to 120 PSI (8.4 BAR)
• Temperature range: up to 130°F (54°C)
• Inlet and outlet size: 1 1/2", 2" MNPT
• Filter and Disc Materials
      Housing and discs: polypropylene
• O-ring: EPDM
      Pressure testing ports: polypropylene
      Pressure testing seals: natural rubber BR
      Disc cylinder assembly: polypropylene / PBT
      Spring: stainless steel 304

Ensure optimal filtration with the DIG 120 Mesh Disk Element Sets for 2 in. Long Filters. These 120 mesh disk sets are designed for in-depth filtration, retaining organic matter as sediments accumulate on the outer face of the stacked disks. The clean water flows through the tightly pressed stacked disks and out the middle of the filter, providing high filtration efficiency.

Made of UV-resistant, durable plastic material, these disk elements can withstand even the most adverse conditions. They offer excellent resistance to most common chemicals and are easy to maintain - simply extract the disks for cleaning. The interchangeable color-coded disks and stainless-steel screen elements provide a wide range of filtration degrees and options to meet your specific needs.
