Febco 825YA Angle RPZ Backflow Preventer 3/4 in. FPT | FE825YA-075

In stock
Free Shipping on Orders over $149
Sales Price $621.45 Our Price $1,008.95 You save 38%

FEBCO FE825YA-075 3/4 in. Angle RPZ Backflow Preventer:

Series FE825YA Small Footprint "N-Shape" Design Reduced Pressure Zone Assemblies are used to protect against high hazard (toxic) fluids in water services to industrial plants, hospitals, morgues, mortuaries, and chemical plants. They are also used in irrigation systems, boiler feed, water lines and other installations requiring maximum protection. Maximum Working Pressure: 175psi (12.1 bar).

Pressure - Temperature
  • Maximum Working Pressure: 175psi (12.1 bar)
  • Hydrostatic Test Press: 350psi (24.1 bar)
  • Temperature Range: 32F to 140F (0C to 60C)
  • Valve Body: Cast Copper Silicon Alloy
  • Elastomers: Nitrile Seat Discs
  • Diaphragms: Nitrile, fabric reinforced
  • Springs: Stainless Steel
Approvals - Standards
  • AWWA C511 Conformance
  • Approved by the Foundation for Cross-Connection Control and Hydraulic Research at the University of Southern California.
Typical Installation: FE825YA-075 3/4 inch Angle RPZ Angle RPZ Assemblies Features & Benefits
  • Installation versatility simplfies new and retrofit installations..
  • Eliminates pipe elbows, nipples, and unions from the installation.
  • Reduces installation time, labor costs. and materials.
  • Integral flanged union connections allow assembly to be removed from the line for freeze protection or maintenance without danger of spool substitution.
  • Approved by the Foundation for Cross-Connection Control and Hydraulic Research at the University of Southern California.
  • Modular relief valve and check valve internal componets for ease of maintenance.
  • Smaller, less costly protective enclosure can be used to provide freeze and vandalism protection due to compact size of valve.
  • Field tested design for reliability and performance.
  • Replaceable seat rings for longer valve life.
  • Low head loss for optimum performance.
More Information
Test Cocks 4 FEMALE
Max Working Pressure 175 PSI
Hydrostatic Test Pressure 350 PSI
Temperature Range 32F to 140F
Main Valve Body Materials Bronze
Relief Valve Body Bronze
Elastomers Nitrile Seat Discs
Diaphragms Nitrile, Fabric reinforced
Springs Stainless Steel
Warranty 1 Year
Size 3/4 in.
Connection FPT
Lead Free Not Lead Free
Brand Febco
Specifications (500.83 kB)
