Rain Bird VAN Adjustable Nozzle 4 ft | 4VAN

In stock
SKU
4VAN
Free Shipping on Orders over $149
On-Sale $0.79 List Price $1.41
Bag of 25
$0.77 / each
Case of 250
$0.76 / each

Rain Bird 4VAN Female Variable Adjustable Nozzle (0-330 degree)

  • 4' Variable Arc
  • Adjustable Nozzle 0° to 330°
  • Female threaded to fit male threaded sprays and adapters

Features & Benefits

Rain Bird VAN Nozzles ensure the diverse needs of your landscape, including oddly shaped corners, will be evenly watered, leaving you with a beautiful lawn and garden. They can be adjusted to the exact pattern of your lawn, ensuring your landscape will be precisely watered, so you don't need to worry about it. They are ideal for odd shaped corners and smaller grassy areas around sidewalks and driveways; they can also be used for watering flowerbeds or shrubs.

  • Easy arc adjustment from 0° to 330° for 4 VAN
  • Simple twist of center collar increases or decreases arc setting
  • Stainless steel adjustment screw to adjust flow and radius.
  • Shipped with blue filter screen (.02 x .02) to maintain precise radius adjustment and prevent clogging.
  • Fits all Rain Bird sprinklers and shrub adapters.

Product Details

  • Pressure: 15 to 30 psi (1 to 2,1 bar)
  • 4-VAN: 3 to 4 feet (0,9 to 1,2 m)
4VAN 4 ft Adjustable Spray
ARC PRESSURE PSI RADIUS FT. FLOW GPM  PRECIP IN/H  PRECIP IN/H
Rain Bird 4VAN Female Variable Adjustable Nozzle (0-330 degree)
15 3 0.62 7.23 8.35
20 3 0.70 8.17 9.43
25 4 0.80 5.25 6.06
30 4 0.88 5.78 6.67
ARC PRESSURE PSI RADIUS FT. FLOW GPM  PRECIP IN/H  PRECIP IN/H
Rain Bird 4VAN Female Variable Adjustable Nozzle (0-330 degree)
15 3 0.52 7.42 8.57
20 3 0.58 8.27 9.55
25 4 0.66 5.29 6.11
30 4 0.73 5.86 6.77
ARC PRESSURE PSI RADIUS FT. FLOW GPM  PRECIP IN/H  PRECIP IN/H
Rain Bird 4VAN Female Variable Adjustable Nozzle (0-330 degree)
15 3 0.32 6.84 7.90
20 3 0.37 7.91 9.13
25 4 0.41 4.93 5.69
30 4 0.45 5.41 6.25
ARC PRESSURE PSI RADIUS FT. FLOW GPM  PRECIP IN/H  PRECIP IN/H
Rain Bird 4VAN Female Variable Adjustable Nozzle (0-330 degree)
15 3 0.21 8.98 10.37
20 3 0.24 10.27 11.86
25 4 0.26 6.26 7.23
30 4 0.29 6.98 8.06



Related Articles & Videos

Articles

Videos

More Information
Brand Rain Bird
Type Variable Adjustable Nozzle
Max PSI 30 PSI
Operating PSI 15 - 30 PSI
Warranty 3 Years
Spray Pattern Adjustable Arc
Connection Female
Spray Radius 4 ft
