Rain Bird XACZ 0.02 - 5 GPM Drip Zone Assembly 3/4 in. FPT | XACZ075PRF

SKU
XACZ075PRF
Free Shipping on Orders over $149
Sales Price $58.95 Our Price $80.95 You save 27%
Quantity of 10
$44.59 / each

Rain Bird XACZ 0.02 - 5 GPM Drip Zone Assembly 3/4 in. FPT

  • Size: 3/4 in.
  • Connection: FPT
  • Flow Rate: 0.02 - 5 GPM

Features & Benefits

  • Reliable Control Zone Kits that include the Low Flow Valve, the only valve on the market that can handle low flows (below 3 GPM) without weeping
  • Complete, two-piece Control Zone Kits include the field-proven Low Flow Anti-Siphon Valve that has an atmospheric vacuum breaker for backflow prevention and an IAPMO rating
  • These PR Filter kits provide on/off control, filtration, and pressure regulation with only two parts; so there is less chance of leakage at the connections, both at installation and over the life of the system

Product Details

Operating Range

  • Flow: 0.20 to 5.0 gpm (0.8 to 18.9 l/m)
  • Inlet pressure: 20 to 150 psi (1.4 to 10.3 bar)
  • Filtration: 200 mesh stainless steel screen (75 microns)
  • Regulated pressure: 30 psi (2.1 bar)

Installation Note:

When installing indoors or on a design where the emission points are more than 5ft. above the Control Zone Kit, you must install a check valve after the pressure-regulating filter (RBY or Basket Filter).  The regulator has a permeable white dot that is designed to relieve excess pressure by slowly releasing water droplets.

The filter must be installed downstream of any valve; the warranty will be void if installed under constant pressure.


More Information
Brand Rain Bird
Operating PSI 20 - 150 PSI
Filter 200 Mesh
Warranty 3 Years
Size 3/4 in.
Flow Rate 0.02 - 5 GPM
Connection FPT
Pressure Regulator 30 PSI
Type Drip Zone Assembly
Specifications (91.61 kB)
