The PGP Ultra takes the foundation of the best-selling PGP Rotor and raises the bar with a variety of new features developed over three decades of research, customer feedback, and lab testing. Among the most notable improvements of the PGP Ultra is its non-strippable drive and automatic arc return.
These two features work to allow the turret to be turned without causing damage, and return the turret to its original arc regardless of where it is turned. The PGP-04 pressure regulated bodies will take incoming pressures of 50-100 PSI and reduce them to 45 PSI.
The Hunter PRB rotors allow the nozzles to operate at peak efficiency, saving up to 25 percent more water. Having the pressure regulator in the body allows it to remain in place and functional even if the original riser is removed and replaced for service.
Pressure-regulated body (45 PSI) reduces high incoming pressure to increase nozzle efficiency
Patented automatic arc return feature returns the turret back to the original arc pattern if vandalized; adjustable arc from 50° to 360°
Non-strippable drive mechanism is protected from damage if turned in the opposite direction of travel
Part- and full-circle in one model for flexibility across landscapes and reduced inventory
Headed and slotted setscrew allows radius adjustment with a Hunter wrench or flat-blade screwdriver
FloStop® closes the flow of water from individual sprinklers, to change the nozzle or perform repairs (I-20 only)
Flat-top nozzles allow fast, easy insertion
QuickCheck™ arc mechanism for fast arc adjustment
Available stainless steel riser for extra durability
Drain check valve prevents low-head drainage (up to 10' of elevation)
|Application||Residential And Commercial|
|Inlet Size||3/4 in.|
|Pressure Range (PSI)||25-70|
|Spray Pattern||Part Circle Adjustable (50 - 360)|
|Spray Radius||17 ft. - 46 ft.|
|Advanced Features||Pressure Regulation|
|Pop-Up Height||4 in.|
|Check Valve||No Check Valve|
